Feig Electronic TST WU - Page 14

TST Expanded Startup WU
FEIG ELECTRONIC GmbH Page 14 of 18 WU_erweiterte_ Inbetriebnahme4_GB.doc
Value Function Contact
type
End position Hold-open
time
Clear
time
Direction ON
Delay
OFF Delay LCD-Text Test
1003
Deactivate
intermediate stop
N.O. - - - - Without Without Deacti-vation No
1004
Deactivate detector
commands from
outside
N.O. - - - - Without Without Deacti-vation No
1101
Photeye pre-limit
switch
N.O. - - - - Without Without Pre-Limit Photo No
1102
Intermediate stop limit
switch
N.O. - - - - Without Without Limit Intermed. No
1103
Intermediate stop pre-
limit switch
N.O. - - - - Without Without PreLim Interm. No
1104
Safety edge pre-limit
switch
N.O. - - - - Without Without PreLimit Edge No
1105
Safety edge pre-limit
switch
N.C. - - - - Without Without PreLimit Edge No
1106
Upper pre-limit switch N.O. - - - - Without Without PreLimit Open No
1107
Upper pre-limit switch N.C. - - - - Without Without PreLimit Open No
1108
Lower pre-limit switch N.O. - - - - Without Without PreLimit Close No
1109
Lower pre-limit switch N.C. - - - - Without Without PreLimit Close No
1110
Endswitch Open N.C. - - - - Without Without Limit Open No
1111
Endswitch Close N.C. - - Without Without Limit Close No
1112
Reference switch N.O. - - Without Without Reference - No
1113
Reference switch N.C. - - Without Without Reference No
1114
reserved - - - Without Without - No
