Feig Electronic TST WU - Page 13

TST Expanded Startup WU
FEIG ELECTRONIC GmbH Page 13 of 18 WU_erweiterte_ Inbetriebnahme4_GB.doc
Value Function Contact
type
End position Hold-open
time
Clear
time
Direction ON
Delay
OFF Delay LCD-Text Test
0505
Photoeye with
through-travel
sensing 1
N.O. as before as before With Both Without Without Photo-eye No
0506
Photoeye with
through-travel
sensing 2
N.C. as before
Min. hold-
open time
With Both Without Without Photo-eye No
0507
Photoeye N.O. as before as before With Both Without Without Photo-eye No
0601
Auto / Manual N.O. - - - - Without Without Dead-man No
0602
Auto /
semi automatic
N.O. - - - - Without Without Dead-man No
0701
CLOSE N.O. - - - With Without Without Close No
0801
Locking in lower end
position, deadman not
possible
N.O. - - - - Without Without Locked Closed No
0802
Locking in lower end
position, deadman
possible
N.O. - - - - Without Without Locked Closed No
0803
Locking in position N.O.
Locking in Door Open
position
- - - Without Without Locked Interm No
0804
Locking in position N.O.
Locking in Door Close
position
- - - Without Without Locked Interm No
0901
Cross-traffic, OPEN1
and DET1
N.O. - - - - Without Without Cross Traffic No
0902
Cross-traffic, OPEN2
and DET2
N.O. - - - - Without Without Cross Traffic No
0903
Cross-traffic,
OPEN1+2 and
DET1+2
N.O. - - - - Without Without Cross Traffic No
1001
Deactivate hold-open
time
N.O. - - - - Without Without Deacti-vation No
1002
Deactivate airlock N.O. - - - - Without Without Deacti-vation No
