Feig Electronic TST WU - Page 12

TST Expanded Startup WU
FEIG ELECTRONIC GmbH Page 12 of 18 WU_erweiterte_ Inbetriebnahme4_GB.doc
Value Function Contact
type
End position Hold-open
time
Clear
time
Direction ON
Delay
OFF Delay LCD-Text Test
0203
Pull switch
OPEN -> Endposition
-> CLOSE -> OPEN
N.O.
1. Intermediate stop
2. Upper
3. Pull straight up 2x
Without With Both Without Without Pull switch No
0204
Pull switch
OPEN -> Endposition
-> CLOSE -> OPEN
N.O. Upper Without With Both Without Without Pull switch No
0207
Pull switch
OPEN -> Endposition
-> CLOSE -> OPEN
N.O. Intermediate stop With With From inside Without Without Pull Swit.int No
0208
Pull switch
OPEN -> Endposition
-> CLOSE -> OPEN
N.O.
1. Intermediate stop
2. Upper
With With From outside Without Without Pull Swit.ext No
0209
Pull switch
OPEN -> STOP ->
CLOSE -> STOP
N.O.
1. Intermediate stop
2. Upper
Without With Both Without Without Pull switch No
0301
Permanent OPEN N.O.
1. Intermediate stop
2. Upper
Without Without Both Without Without Perm. Open No
0304
Permanent OPEN N.O. Upper Without Without No Without Without Perm. Open No
0401
Stop N.C. - - - - Without Without Stop No
0402
Stop N.O. - - - - Without Without Stop No
0403
Stop, Reset possible N.C. - - - - Without Without Stop No
0404
Stop. Reset possible N.O. - - - - Without Without Stop No
0501
Photoeye N.C. as before as before With Both Without Without Photoeye No
0502
Photoeye with
through-travel
sensing 1
N.C. as before as before With Both Without Without Photo-eye No
0504
Photoeye N.C. as before
Min. hold-
open time
With Both Without Without Photo-eye No
