TST Erweiterte Inbetriebnahme WU
FEIG ELECTRONIC GmbH Seite 11 von 18 WU_erweiterte_ Inbetriebnahme4_GB.doc
Table 1: Input profiles
Value Function Contact
type
End position Hold-open
time
Clear
time
Direction ON
Delay
OFF Delay LCD-Text Test
0000
Input
deactivated
0101
OPEN 1
N.O.
1
Upper With With Both Without Without OPEN No
0102
OPEN 1 N.O. Intermediate stop With With Both Without Without OPEN No
0103
OPEN airlock N.O. Intermediate stop With With Both Without Without OPEN No
0104
OPEN 1 N.O. Intermediate stop With With from outside Without Without OPEN No
0105
OPEN 2 N.O. Upper With With Both Without Without OPEN No
0106
OPEN 2 N.O. Upper With With from inside Without Without OPEN No
0107
OPEN 4
2
N.O. Upper With With Both Without Without OPEN No
0108
OPEN 2 N.O. Intermediate stop With With Both Without Without OPEN No
0109
OPEN 3 N.O. Intermediate stop With With Both Without Without OPEN No
0110
OPEN 1 N.O. Upper With With from outside Without Without OPEN No
0111
OPEN 1 N.C. Upper With Without Both Without Without OPEN No
0112
OPEN 1 N.O.
3
Upper Without With Both Without Without OPEN No
0114
OPEN airlock N.O. Intermediate stop With With from inside Without Without OPEN No
0116
OPEN 1 N.O. Upper Without With from outside Without Without OPEN No
0117
OPEN 1 N.O. Upper Without With from inside Without Without OPEN No
0120
OPEN 2 N.O. Upper With Without from inside Without Without OPEN No
0121
OPEN 1 N.O. Upper With Without from outside Without Without OPEN No
0124
OPEN 2 N.O. Intermediate stop With With from inside Without Without OPEN intern No
0125
OPEN 2 N.O. Upper With With from inside Without Without OPEN intern No
0129
OPEN 2 N.O. Intermediate stop With With from outside Without Without OPEN extern No
0201
Pull switch
OPEN -> Endposition
-> CLOSE -> OPEN
N.O.
1. Intermediate stop
2. Upper
With With Both Without Without Pull switch No
0202
Pull switch
OPEN -> Endposition
-> CLOSE -> OPEN
N.O.
1. Intermediate stop
2. Upper
Without With Both Without Without Pull switch No
1
N.C. = normally closed, N.O. = normally open
2
OPEN 3 and OPEN 4 cannot be locked out.
3
N.C. = normally closed, N.O. = normally open
