Flowchart B
Indicator lights
Empty
wastebasket, if
needed
Clean bin full
sensors
Open/close door;
listen for switch
sound; check
light
Procedure:
Replace Door
Ajar Switch
Replace basket
full sensors, if
needed
Door Ajar light
is on
Press reverse &
manual forward
switches to clear
jam
Allow motor to
cool, then restart
shredder
Basket Full light
is on
Paper Jam light
is on
Replace operator
panel PC board
Procedure:
Replace Basket
Full Sensor
Procedure:
Replace
Operator Panel
PC Board
Is the light
still on?
Yes
