Flowchart E
Frequent Paper Jams
Confetti Cut
Shredders
Jams occur at
rated or if under
fed
Jams occur if
over fed
Reduce quantity
of paper fed
Check current
limit adjustment
setting
Procedure:
Set Current
Limit
Adjustment*
If slippage,
replace cutting
cylinder
If alignment,
adjust timing
Procedure:
Adjust Cutting
Cylinder Timing
Procedure:
Replace Cutting
Cylinder
Check cutting
cylinder teeth for
slippage &
alignment
Run shredder
using rated
paper quantities
*Current limit is factory preset on original pc board.
Applies to replacement pc boards only.
