REMOTE CONTROLLER - USER MENU
DISPLAY
The display function is used to set the interface, the main items is language, bac-
klight, buzzer and screen lock time:
SERVICE INFORMATION
SERVICE
CALL
LANGUAGE
BACKLIGHT
BUZZER
SCREEN LOCK TIME
EN
ON
ON
120SEC
ERROR
CODE
SCROLLENTER
OK
PARAMETER DISPLAY
fig. 95 -
Use ‘’OK’’ to enter and use ‘’◄’’,’’►’’,’’▼’’,’’▲’’ to scroll.
Information: IT (Italian), EN (english), ecc
7.15 Operation parameter
This menu is for installer or service engineer to see all the operation parameters.
■ At home page, go to ‘’MENU’’ > ‘’OPERATION PARAMETER’’.
■ Press ‘’OK’’. There are five pages for the operating parameter as following. Use
‘’▼’’, ‘’▲’’ to scroll.
OPERATION PARAMETER
P2 COMP. PRESSURE2 --kPa
POWER CONSUMPTION OKWH
SCROLL 5/5
OPERATION PARAMETER
T1 WATER FLOW TEMP. 25°C
30°C
T2 PLATE F-OUT TEMP.
45°C
T2B PLATE F-IN TEMP.
-7°C
T3 OUTDOOR EXCHANGE TEMP.
-7°C
T4 OUTDOOR AIR TEMP.
-7°C
T5 OUTDOOR AIR TEMP.
SCROLL 3/5
OPERATION PARAMETER
COMP.RUN TIME4 1000HOUR
EXPANSION VALUE 240P
600 R/MINFAN SPEED
0 ABACKUP HEATER1 CURRENT
0 ABACKUP HEATER2 CURRENT
T1 LEAVING WATER TEMP.1 25°C
SCROLL 2/5
OPERATION PARAMETER
Ta Room temp
25°C
P1 COMP. PRESSURE1 200kPa
SCROLL 4/5
25°C
Tw-0 PLATE W-OUTLET TEMP.
25°C
Tw-I PLATE W-INLET TEMP.
25°C
Th COMP.SUCTION TEMP.
25°C
Th COMP.SUCTION TEMP.
OPERATION PARAMETER
OPERATE MODE COOL
COMPRESSOR CURRENT 12A
24HzCOMPRESSOR FREQUNCY
54MINCOMP.RUN TIME1
65MINCOMP.RUN TIME2
10MIN
COMP.RUN TIME3
SCROLL 1/5
fig. 96 -
OPERATION PARAMETER
P2 COMP. PRESSURE2 --kPa
POWER CONSUMPTION OKWH
SCROLL 5/5
OPERATION PARAMETER
T1 WATER FLOW TEMP. 25°C
30°C
T2 PLATE F-OUT TEMP.
45°C
T2B PLATE F-IN TEMP.
-7°C
T3 OUTDOOR EXCHANGE TEMP.
-7°C
T4 OUTDOOR AIR TEMP.
-7°C
T5 OUTDOOR AIR TEMP.
SCROLL 3/5
OPERATION PARAMETER
COMP.RUN TIME4 1000HOUR
EXPANSION VALUE 240P
600 R/MINFAN SPEED
0 ABACKUP HEATER1 CURRENT
0 ABACKUP HEATER2 CURRENT
T1 LEAVING WATER TEMP.1 25°C
SCROLL 2/5
OPERATION PARAMETER
Ta Room temp
25°C
P1 COMP. PRESSURE1 200kPa
SCROLL 4/5
25°C
Tw-0 PLATE W-OUTLET TEMP.
25°C
Tw-I PLATE W-INLET TEMP.
25°C
Th COMP.SUCTION TEMP.
25°C
Th COMP.SUCTION TEMP.
OPERATION PARAMETER
OPERATE MODE COOL
COMPRESSOR CURRENT 12A
24HzCOMPRESSOR FREQUNCY
54MINCOMP.RUN TIME1
65MINCOMP.RUN TIME2
10MIN
COMP.RUN TIME3
SCROLL 1/5
fig. 97 -
☞ NOTE
if some parameter is not be activated (or available), the parameter will show “--”.
7.16 For Serviceman
About For Serviceman
FOR SERVICEMAN is used for installater and service engineer.
■ Setting the composition of equipment.
■ Setting the parameters.
Go to ‘’MENU’’ > ‘’FOR SERVICEMAN’’. Press ‘’OK’’.
FOR SERVICEMAN
Please input the password:
ADJUST SCROLLENTER
OK
0 0 0
fig. 98 -
How To Exit For SERVICEMAN
If you have set all the parameter.
Press ‘‘BACK’’, the following page will be appear:
FOR SERVICEMAN
Do you want to exit the for
serviceman?
SCROLLCONFIRM
OK
NO YES
fig. 99 -
Selecting ‘YES’ ‘and pressing’ ‘OK’ ‘exits the menu.
☞ NOTE
When you exit from the menu FOR SERVICEMAN, the unit will be turned off.
