GENERAL SPECIFICATIONS
DESCRIPTION OF COMPONENTS
1. Heat exchange bank
Bank with 3 ranks made of copper pipe and aluminium finning locked together by mechanical expansion of the
pipes. The manifolds in the upper part of the bank are equipped with air vents while the ones in the lower part have
holes to drain out the water. Both manifolds have a housing for the temperature probe of the feed water.
2. Air filter
Can be easily removed and regenerated by simply washing in water.
3. Cabinet
Partly made of steel sheet coated with epoxy powder paint to ensure a high resistance to rust, and partly of anti-
UV thermoplastic material to protect against ultraviolet rays.
VM-B version: there are grilles to distribute the air in the upper part and a door to access the control panel. Both
are made of anti-UV thermoplastic material.
VM-F version: there are grilles to distribute the air in the upper part and a door to access the control panel. Both
are made of anti-UV thermoplastic material.
The cabinet also has a front grille made of anti-UV thermoplastic material which takes in the air.
4. Bearing structure
Made of adequately thick galvanized sheet metal. The rear part has slots to fix the appliance in place. Models
without cabinets are covered at the front by a panel to protect the ventilating unit.
5. Condensation tray
Made of thermoplastic material to prevent rust from forming. Allows the machine to be installed either vertically or
horizontally. Thanks to its shape, the drops of condensation that form on the manifolds when the appliance is ope-
rating in cold mode are collected in the tray when the machine is installed horizontally. The condensation is then
eliminated from the tray which is installed on both sides of the appliance so that the bank can be turned if neces-
sary.
6. Fan motor
The electric motor is protected against overloads, has three speed settings, infinitely engaged capacitator, is
directly coupled to the fans and has elastic shock-absorbing supports. Centrifugal series: has centrifugal fans with
double intake and long blades to achieve a high flow rate at a low rpm rate.
7. Wet connections
Positioned on the left-hand side, the connections are the ¾" type. The bank can be turned if necessary.
8. Control panel (described in the ACCESSORIES section of this manual)
PACKING AND CONTENTS
The convector fans are shipped in standard packaging consisting of a cardboard box inside which angular pieces
of cardboard are fitted to protect the appliance from damage during the handling phase. The cardboard box con-
tains:
• 1 convector fan
• 1 cardboard template for assembly purposes
• Instruction manuals
