GENERAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
CENTRIFUGAL Series
MODEL 15 20 30 40 60 80 100 120
Max. W 2800 3650 5500 6500 9400 12500 14900 15800
Med. W 2400 3150 4550 5450 7900 10800 12500 13270
Min. W 1800 2250 3400 4000 5800 8300 9600 10000
Water flow rate l/h
241 314 473 559 808 1075 1281 1359
Load losses on wet side
(E)
Kpa
2.9 4.9 13.2 18.5 18.1 17.7 10.8 12.1
Load losses on wet side
(E)
Kpa
2 3 8 15 14 12 8 10.0
Therm. power
(E)(1)
W
1700 2050 3200 3850 5100 7200 8700 9300
Max. W
(E)
1100 1400 2100 2800 4000 4900 6100 6850
Med. W 980 1200 1850 2450 3550 4350 5500 6100
Min. W 770 950 1450 1900 2800 3600 4400 5000
Water flow rate l/h
108 142 219 271 353 434 533 598
Water flow rate
(E)
l/h
189 241 361 482 688 843 1049 1178
Dehumidifying max. speed g/h
230 275 500 650 870 930 1160 1350
Load losses on wet side Kpa 1.7 3 8.6 13.2 4.1 6.2 12.8 16.1
Load losses on wet side
(E)
Kpa
2.4 3.9 10.6 18.5 18 14.9 9.9 12.5
Therm.pow. of heat.el. W 800 800 1500 1500 2200 2200 2600 2600
Max. m
3
/h
215 280 410 515 750 1050 1200 1350
Med. m
3
/h
170 210 310 400 600 850 970 1070
Min. m
3
/h
110 140 220 290 410 570 670 720
N° fans 11122233
Max. dB(A)
(E)
45 48 52 54 55 61 63 65
Med. dB(A)
(E)
39 42 45 47 50 58 59 60
Min. dB(A)
(E)
32 35 39 41 39 48 51 52
Max.motor pow. rat.
(E)
W
35 38 55 76 85 144 163 200
Main bank connections Ø 3/4” 3/4” 3/4” 3/4” 3/4” 3/4” 3/4” 3/4”
Suppl.bank connections Ø
1/2” 1/2” 1/2” 1/2” 1/2” 1/2” 1/2” 1/2”
Thermal power
Refrigerating
capacity
Max. W
(E)
1250 1650 2550 3150 4100 5050 6200 6950
Med. W 1070 1420 2110 2640 3440 4360 5200 6190
Min. W8601130175021502820348042504800
Thermal power
of supplemen-
tary bank
Air flow rate
Sound rating
NOTES:
Power source voltage rating: 230-1-50 [V-F-Hz]
Heating mode:
• Ambient air temp.: 20°C.
• Inlet water temp.: 70°C, water
DD
t 10°C at top fan speed; water flow rate same as top speed at medium and minimum fan speeds.
• (1) Inlet water temp. 50°C water flow rate as in cooling mode.
Fan speed: max
Cooling mode:
• Ambient air temp.: 27°C D.B. 19°C W.B
• Inlet water temp.: 7°C, water
DD
t 5°C at top fan speed; water flow rate same as top speed at medium and minimum fan speeds.
• Fan speed: max
(2) Sound pressure in 100 m
3
room with 0.5 sec reverberation time.
(E) EUROVENT certified data
Max. dB(A) 36 39 43 45 46 52 54 56
Med. dB(A) 30 33 36 38 41 49 50 51
Min. dB(A) 23 26 30 32 30 39 42 43
Sound
pressure
(2)
3R bank water contents l 0.82 0.82 1.26 1.26 1.88 1.88 2.42 2.42
1R bank water contents l
0.22 0.22 0.36 0.36 0.5 0.5 0.64 0.64
Condensation outlet conn. Ø
16 16 16 16 16 16 16 16
Tab.2
