GENERAL SPECIFICATIONS
OVERALL DIMENSIONS OF DUCTED MODEL
MODEL 15 20 30 40 60 80 100 120
A (mm)
474
494
216
Ø 16
A
474 724 724 974 974 1224 1224
Weight (Kg) 11 11 15 15 22 22 29 29
MODEL 15 20 30 40 60 80 100 120
A(mm)
41541566566591591511651165
OVERALL DIMENSIONS OF BRACKETING
77.5
494
Overall dimensions of casing
(if used)
60
278
137.5
A
137.5
Ø 16
Fig.11
Fig.12
