6
DESCRIPTION OF THE APPLIANCE
PURPOSE OF THE MACHINE
The convector fan is an appliance that treats the air in the room in both summer (bank supplied with cold water) and
winter (bank supplied with hot water).
AVAILABLE VERSIONS AND INSTALLATION METHODS
The range of centrifugal convector fans includes three versions. Different power ratings are available for each.
1: VM-B - Convector fan with cabinet and intake from below
Consists of a sheet metal cabinet, a delivery grille with doors to access the
panel (if applicable) made of thermoplastic material plus an air filter that can
be re-generated, installed on a metal frame with covering profile in plastic
material housed on guides formed in the lower part of the frame
.
- Installation mode
VERTICAL
WALL-MOUNTED
VERTICAL AND STANDING HORIZONTAL
Fig.1
Fig.2
