7
DESCRIPTION OF THE APPLIANCE
2: VM-F - Convector fan with cabinet and frontal intake
Consisting of a sheet metal cabinet, a delivery grille with doors to access a
panel if installed in thermoplastic material, plus an air filter that can be re-gene-
rated installed in the front grille, made of plastic material and sheet metal and
closing at the bottom
.
- Installation mode
VERTICAL WALL-MOUNTED
HORIZONTAL ON CEILING
Fig.3
Fig.4
