3. Mounting and installation
14 Festo P.BE-CMMS-FHPP-DN-SW-EN en 1103a
on the front plate in accordance with the DeviceNet specification. A two-colour LED shows
information about the device and the communication status. It has been designed as a
combined module/network status (MSN) LED.
Next to the contacts CAN_L and CAN_H for the network connection, 24 V DC must be
connected to V+ and V- in order to supply the den CAN transceiver.
The cable screening is connected with the contact Drain/Shield.
In order to connect the DeviceNet interface correctly with the network, refer to the very
detailed "Planning and Installation Manual" on the ODVA homepage:
http://www.odva.org
The different types of network supply are represented in detail there.
For the best results we recommend that you use ready-made components.
