Festo CMSX Series - SW-Ver - Software Version; Actfct - Actuator Function; Acttyp − Actuator Type

Index Parameters and
value range
Description Reference
ActTyp Actuator type
– linear linear
c
– rotary rotary
è 9.4.1.3 − Actuator
type
SafPos Safety position of the positioner
– safe Regulating effect opening/closing
d
– freeze Regulating effect holding
è 9.4.1.4 - Safety
position of the
positioner
Tab. 9 Menu IDENT: identification of the positioner
9.4.1.1 SW-Ver – Software version
This parameter can be used to display the software version of the positioner. The identification is
divided into three levels according to NE53.
Value range Description
XX – Compatibility is compromised
– Operating instructions and display and operating components change
YY – Changes in functionality and operation
– Compatibility is maintained
– Operating instructions and display and operating components change
ZZ – Minimal changes (e.g.troubleshooting, availability)
– Compatibility and functionality are maintained
– Operating instructions and display and operating components do not
change
Tab. 10
9.4.1.2 ActFct – Actuator function
This parameter can be used to display the actuator function supported by the positioner.
Value range Description
single single-acting drives (CMSX-P-...-D-...)
double double-acting drives (CMSX-P-...-S-...)
Tab. 11
9.4.1.3 ActTyp − Actuator type
This parameter can be used to set the actuator type for double-acting drives. If a single-acting drive is
connected, the parameter setting is ignored. Every parameter option is assigned a control type.
Commissioning
28 Festo — CMSX-...-C-U-F1-... — 2019-09d
