Festo CMSX Series - Do1 Log - Digital Output 2 Logic; Errlog - Digital Alarm Output Logic; DO-Mod - Switching Mode of Digital Outputs

Value range Description
inactiv Digital output 2 deactivated (factory setting)
lowlmt Lower position limit reached(2%)
uplmt Upper position limit reached(98%)
bothlmt Upper(98%) or lower(2%) position limit
reached
Tab. 38
9.4.3.12 DO1Log – Digital output 2 logic
This parameter can be used to set the switching logic at digital output 2.
Value range Description
lowact Switching logic active low
Low level is output when digital output 2 is activ-
ated.
highact Switching logic active high (factory setting)
High level is output when digital output 2 is activ-
ated.
Tab. 39
9.4.3.13 ErrLog - Digital alarm output logic
The switching logic at the digital alarm input can be set with this parameter. The digital alarm output
is activated in the following cases:
– Initialisation not successful
– Setpoint value outside the specification
– Actuator cannot reach required target position
Value range Description
lowact Switching logic active low
highact Switching logic active high (factory setting)
Tab. 40
9.4.3.14 DO-Mod – Switching mode of digital outputs
The switching mode of the digital outputs (D-OUT-1, D-OUT-2, ALARM) can be set with this parameter.
Commissioning
46 Festo — CMSX-...-C-U-F1-... — 2019-09d
