Value range Description
PNP PNP polarity of the switching outputs (D-OUT-1,
D-OUT-2, ALARM)
NPN NPN polarity of the switching outputs (D-OUT-1,
D-OUT-2, ALARM)
Tab. 41
9.4.4 Parameter overview – 4 DIAG
Index Parameters and
value range
Description Reference
a V1CYCL
– 0…1E10
Number of switching cycles solenoid valve 1
b V2CYCL
– 0…1E10
Number of switching cycles solenoid valve 2
c V3CYCL
– 0…1E10
Number of switching cycles solenoid valve 3
d V4CYCL
– 0…1E10
Number of switching cycles solenoid valve 4
è 9.4.4.1 V1CYCL,
V2CYCL, V3CYCL,
V4CYCL - number of
switching cycles
solenoid valve
Tab. 42 Menu DIAG: diagnostic functions
9.4.4.1 V1CYCL, V2CYCL, V3CYCL, V4CYCL - number of switching cycles solenoid valve
The counters sum up the control processes of the solenoid valves and serve to evaluate the switching
frequency. The characteristic service life value of the valve block depends on the load. On average, it
amounts to approx. 10 million switching cycles for each of the solenoid valves.
9.4.5 Parameter overview – 5 INIT
Index Parameter Description Reference
a A-Init Start automatic initialisation è 9.4.5.1 – Start
automatic
initialisation
b Sensor Start sensor test è 9.4.5.2 – Check
sensing range of the
path/angle sensor
Tab. 43 INIT menu: commissioning
9.4.5.1 A-Init – Start automatic initialisation
The automatic initialisation can be started with this parameter. The following values are determined
automatically during the initialisation routine:
– maximum possible mechanical stroke range
Commissioning
