Festo CMSX Series - DI-Log - Digital Input Logic; Do1 Fct - Digital Output 1 Function; Do1 Log - Digital Output 1 Logic; Do2 Fct - Digital Output 2 Function

Value range Description
a-init automatic initialisation
Tab. 34
9.4.3.8 DI-Log – Digital input logic
The switching logic at the digital input can be set with this parameter.
Value range Description
lowact Switching logic active low
The set function is activated with a low level.
highact Switching logic active high (factory setting)
The set function is activated with a high level.
Tab. 35
9.4.3.9 DO1Fct – Digital output 1 function
This parameter can be used to set the action for which digital output 1 is activated.
Value range Description
inactiv Digital output 1 deactivated (factory setting)
lowlmt Lower position limit reached(2%)
uplmt Upper position limit reached(98%)
bothlmt Upper(98%) or lower(2%) position limit
reached
Tab. 36
9.4.3.10 DO1Log – Digital output 1 logic
This parameter can be used to set the switching logic at digital output 1.
Value range Description
lowact Switching logic active low
Low level is output when digital output 1 is activ-
ated.
highact Switching logic active high (factory setting)
High level is output when digital output 1 is activ-
ated.
Tab. 37
9.4.3.11 DO2Fct – Digital output 2 function
This parameter can be used to set the action for which digital output 2 is activated.
Commissioning
45Festo — CMSX-...-C-U-F1-... — 2019-09d
