Fault description Cause Remedy
Actuator travels to an end posi-
tion, even though another set-
point value is specified
Safety setting active or digital
input active
Deactivate digital input (DI-FCT)
è 9.4.3 Parameter overview - 3
IN/OUT.
Check the electrical connection
(setpoint specification within
the permissible range).
Tab. 45
12 Disassembly
CAUTION!
Pressurised lines
Even if the compressed air feed is shut off the pneumatic ports of the positioner may still be under
pressure.
• Exhaust the pneumatic ports (working ports) before disconnecting the hose assemblies.
12.1 Dismantling CMSX-...
1. Switch off compressed air.
2. Activate in the manual operation base menu: "ManVent".
3. Move actuator until the working ports are completely exhausted.
4. Switch off power supply.
5. Unscrew housing screws (è Fig.1,3 or è Fig.2,3) and remove the housing cover.
6. Loosen electrical and pneumatic connections.
7. Unscrew 4 retaining screws (è Fig.7,3 or è Fig.9,4) and remove the positioner with the
mounting adapter.
13 Disposal
ENVIRONMENT!
Send the packaging and product for environmentally sound recycling in accordance with the current
regulations èwww.festo.com/sp.
14 Technical data
Type CMSX-...-C-U-F1
General
Constructive design digital, electro-pneumatic positioner
Mode of operation
Disassembly
