Type CMSX-...-C-U-F1
CMSX-P-...-C-U-F1-S-... single-acting
CMSX-P-...-C-U-F1-D-... double-acting
Design characteristics
CMSX-P-…-C-U-F1-S-…-A Safety position – pneumatic outlet 4
exhausted
CMSX-P-S-C-U-F1-D-…-A Safety position – pneumatic outlet 4
exhausted, pneumatic outlet 2 pressur-
ised
CMSX-P-…-C-U-F1-…-C Safety position - pneumatic outlets
closed
Mounting position Any
Type of mounting With accessories
Mode of operation of displacement encoder Potentiometer
Sensing range [°] 0…100
Display LCD, backlight
7-segment display
Setting options via display and keys
Deadband size [%] 0.5…10
Pneumatics
Operating pressure [bar] 3…8
Operating medium Compressed air to ISO8573-1:2010
[7:4:4]
Note on the operating medium lubricated operation not possible
Standard nominal flow rate
CMSX-...-50 [l/min] 50
CMSX-...-130 [l/min] 130
Pneumatic connection Gx
Electrics
Nominal operating voltage [V] 24
Operating voltage range DC [V] 21.6…26.4
max. current consumption [mA] 600
Reverse polarity protection for operating voltage connection
Connection resistance [kΩ] < 80
Technical data
