Index Parameters and
value range
Description Reference
DI-Fct Digital input function
– inactiv Digital input function deactivated (factory
setting)
– stop Pneumatic outlets 2 and 4 are closed
– exhaust Exhaust pneumatic outlet 2/pressurise pneu-
matic outlet 4
– pressur Pressurise pneumatic outlet 2/exhaust pneu-
matic outlet 4
g
– a-init Executing automatic initialisation
è 9.4.3.7 - Digital
input function
DI-Log Digital input logic
– lowact Switching logic active low
h
– highact Switching logic active high (factory setting)
è 9.4.3.8 – Digital
input logic
DO1Fct Digital output 1 function
– inactiv Digital output 1 function deactivated (factory
setting)
– lowlmt Feedback of reaching the lower position limit
value(2%).
– uplmt Feedback of reaching the lower position limit
value(98%).
i
– bothlmt Feedback of reaching the upper(2%) or
lower(98%) position limit value
è 9.4.3.9 – Digital
output 1 function
DO1Log Digital output 1 logic
– lowact Switching logic active low
j
– highact Switching logic active high (factory setting)
è 9.4.3.10 – Digital
output 1 logic
DO2Fct Digital output 2 function
– inactiv Digital output 2 function deactivated (factory
setting)
– lowlmt Feedback of reaching the lower position limit
value(2%).
– uplmt Feedback of reaching the lower position limit
value(98%).
k
– bothlmt Feedback of reaching the upper(2%) or
lower(98%) position limit value.
è 9.4.3.11 – Digital
output 2 function
Commissioning
