2. Commissioning
2-12
Festo P.BE-CP-FB13-E-EN en 0112e
Example 1:
CP system with 3 strings, a total of 3 input and 3 output
modules, highest assigned string number = 2.
DP identifier Comment
0 021 6 input bytes
1 037 6 output bytes
Example 2:
CP system with 3 strings, only 3 output modules, highest
assigned string number = 2.
DP identifier Comment
0 037 6 output bytes
