Fig. 3/12: Online diagnosis via diagnostic buffer
Device-specific diagnosis for the Fes to valv e terminal
6. Click the Festo valve terminal 6 instead of the CPU. Y ou
can read further information on the status of the valve
terminal in the window “Module Information”.
