A.4.1 Numbering the modules in the standard EDS file
The data and parameters for the digital and analogue
modules are each grouped together as follows:
Group
Group name Description
Digital module Dat/Par Dig.Mod
Dat/Par Dig.Mod1
Dat/Par Dig.Mod...
Data and parameters of digital module 0
Data and parameters of digital module 1
Data and parameters of digital module ...
Analogue module Dat/Par Ana.Mod
Dat/Par Ana.Mod1
Dat/Par Ana.Mod...
Data and parameters of analogue module 0
Data and parameters of analogue module 1
Data and parameters of analogue module ...
MPA pneumatics
1)
Dat/Par MPA
Dat/Par MPA1
Dat/Par MPA...
Data and parameters of the MPA pneumatics module 0
Data and parameters of the MPA pneumatics module 1
Data and parameters of the MPA pneumatics module ...
Pneumatic interface
2)
Dat/Par PI Mod Data and parameters of the pneumatic interfaces
1)
Only relevant for CPX terminals with MPA pneumatics
2)
Only relevant for CPX terminals with CPA or Midi/Maxi pneumatics
Tab.A/4: Numbering the modules
The number at the end of the group name specifies the
number of the relevant module type within the CPX terminal.
It is not identical to the module position number (see also
Fig.A/1).
The digital modules and the analogue modules are counted
separately in each case from left to right,
beginning with zero.
