2. Commissioning
2−25
Festo P.BE−CPX−FB11−EN en 0503b
Please note
The following applies to an SLC 500 with an Allen−Bradley
scanner type 1747−SDN:
 Change of State / Cyclic" can be used in combination
with the diagnosis via Strobed I/O" only starting with
software version V4.015 of the scanner.
 Polled I/O" with Strobed I/O" is also supported by
earlier versions.
· Assign the I/O addresses of the slave to the
PLCoperands.
· 1. Assign one diagnostic byte to the PLC operands.
4. Load the configuration into the scanner.
2.2.4 Configuration with RSNetWorx for DeviceNet with standard EDS
This section gives instructions on configuring with RSNetWorx
for DeviceNet version 4.01.00 from Rockwell.
Please note
All steps listed refer to the Allen−Bradley scanner
1747−SDN as example. They apply accordingly to other
masters.
Insert the slave into the project/network
RSNetWorx for DeviceNet contains an assistant (EDS Wizard)
which will suppor t you in installing the EDS
file. After instal
ling the EDS−file, you will find the CPX terminal in the Hard
ware" list. By shifting the mouse, you can insert slaves in the
network on the right−hand side.
