C. DeviceNet objects with Modular EDS
C−31
Festo P.BE−CPX−FB11−EN en 0503b
Attr.
no.
Function no.
3488 + n
TypeDescriptionDesignationAccess
110 Get Fault number See System manual chap. 5,
Possible fault messages"
USINT n = 10 * d + 8
111 Get Subsequent
channels
3)
Number of subsequent
channels with the same fault
USINT n = 10 * d + 9
1)
d (diagnostic event) = 0 ... 39; most current diagnostic event = 0
2)
Measured from the moment the power supply is switched on
3)
If the fault number = 0, the contents are also 0. If the fault number lies between 128 ... 199
(fault class 3), the contents are not relevant (servicing required).
C.1.14 Diagnostic trace status object
Object class: 117
Instances: 1
Attr. no.
Access Name Type Function no.
100 Get Number of Trace entries in the diagnostic memory USINT 3482
(bit 0 ... 7)
101 Get Status of diagnostic memory
0: Registering active
1: Registering inactive
BYTE 3483
(bits 0, 1)
102 Get/Set Clear_trace1, access via EDS USINT 
103 Get/Set Clear_trace2, access via explicit messaging;
Confirms activity carried out by resetting (0) the
attribute value
USINT 
104 Get/Set Entries remanent with Power on
1: Inactive
0: Active (presetting)
USINT 3480
(bit 0)
105 Get/Set Run/stop filter 1
0: Stop after 40 entries (save the first 40 entries)
1: Overwrite old entries (save the last 40 entries,
presetting)
USINT 3480
(bit 1)
