2. Commissioning
2−51
Festo P.BE−CPX−FB11−EN en 0503b
A detailed description of the individual parameters as well as
basic information on application can be found in the CPX sys
tem manual (P.BE−CPX−SYS−...).
You can find notes on specific parameters of the DeviceNet in
section 2.3.4.
2.3.4 Notes on specific parameters of the DeviceNet
Reaction of the outputs in theIdle mode
The Idle mode is assumed by the slaves upon request by the
master or scanner. The following applies in this example:
Inputs are transferred
Output channels of the slaves are no longer updated.
In the Idle mode, outputs
can assume one of the following
states:
Digital outputs/valves
Analogue outputs
Freeze current status Freeze current status
Reset the output Desired analogue value
Set the output
Tab.2/18: Possible states in the Idle mode
You can determine the status to be assumed for each output
channel (output or solenoid coil) separately. The standard
setting is Reset output channel".
Further information can be found in the CPX system manual.
