2. Commissioning
2−8
Festo P.BE−CPX−FB38−EN en 0804NH
Configuration
of the bus node
The identification of the bus node and the diagnostics mode
are configured in the Remote I/O operating mode
(seeTab.2/1).
In the Remote Controller operating mode only the identifier
of the bus node will be configured (see Tab.2/3):
Electric modules
Module
type
Module
identifier
1)
Assigned address space
Description Inputs Outputs
Bus node for EtherCAT
In Remote Controller operating mode
CPX−FB38 FB38−RC 8 bytes/64 I 8 bytes/64 O
1)
Module identifier in the handheld unit or in the hardware configuration of the programming
software.
Tab.2/3: Address assignment of the bus node in the Remote Controller
operating mode
