2. Commissioning
2−11
Festo P.BE−CPX−FB38−EN en 0804NH
CPX pneumatic interfaces for
MPA d l t d d l
Module type Module
id tifi
1)
Assignd addr. space
MPA and related modules identifier
1)
Inputs Outputs
VPPM proportional pressure−
regulating valve (type 32)
VPPM−6TA−L−1−F−... VPPM 1 word/
16 I
1 word/
16 O
MPA−P pressure sensor module VMPA−FB−PS−... MPA−P 1 word/16 I 
1)
Module identifier in the handheld unit or in the hardware config. of the programming software
Tab.2/5: Over view of CPX pneumatic interfaces and pneumatic modules (part 2)
Pneumatic interfaces for
Midi/M i CPA VTSA (ISO)
Module type Module
id tifi
1)
Assignd addr. space
Midi/Maxi, CPA, VTSA (ISO) identifier
1)
Inputs Outputs
Pneumatic interface for Midi/Maxi
valves (type 03) with setting
2)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils
1 Ū 32 valve coils (26 can be used)
CPX−GP−03−4.0
(CPX type 03:
1−...−...)
TYPE3 
1 byte/8 O
2 bytes/16 O
3 bytes/24 O
4 bytes/32 O
Pneumatic interface for CPA valves
(type 12) with setting
2)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils (22 can be used)
CPX−GP−CPA−10
CPX−GP−CPA−14
(CPX type 12:
1−...−...)
CPA10/14 
1 byte/8 O
2 bytes/16 O
3 bytes/24 O
Pneumatic interface for VTSA or
VTSA−F pneumatic (ISO, type 44/45)
with adjustment
2)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils
1 Ū 32 valve coils
VABA−10S6−x1
(CPX type
44/45: 1−...−... )
ISO PlugIn or
type44 or
type45
3)

1 byte/8 O
2 bytes/16 O
3 bytes/24 O
4 bytes/32 O
1)
Module identifier in the handheld unit or in the hardware config. of the programming software
2)
Setting with DIL switch in the pneumatic interface
3)
Display text (module identifier) dependent on the version of the handheld unit
Tab.2/6: Over view of CPX pneumatic interfaces and pneumatic modules (part 3)
