DGP(L)−...−B
Festo DGP(L)−...−B 0609g English
38
13 Technical specifications
Size 8 12 18 25 32 40 50 63 80
Medium Depending on use:
as cylinder: Compressed air, dried, filtered, lubricated or non−lubricated
as positioning axis: Compressed air, dried, filtered (5 ìm), non−lubricated
Design Double−acting pneumatic cylinder without piston rod with rigid piston−slide
connection
Operating pressure
(min. ... max.)
3.5 ...
8 bar
2.5 ...
8 bar
2 ... 8 bar 1.5 ... 8 bar
Permitted
temperature range
− 10 ... + 60 °C
Mounting position As desired (recommendation for stroke lengths > 2000 mm and horizontal
mounting: fit the DGP(L)−... with sealing band below)
End position
cushioning
Elastic
cushioning
Pneumatic, adjustable
Cushioning length 16 mm 18 mm 20 mm 30 mm 85 mm
Theoretical stroke
force (at 6 bar)
30 N 68 N 153 N 295 N 483 N 754 N 1178 N 1870 N 3016 N
Theoretical air
consumption
0.003
Nl
0.006
8 Nl
0.018
Nl
0.034
Nl
0.056
Nl
0.088
Nl
0.137
Nl
0.218
Nl
0.352
Nl
Permitted work load component vertical to cylinder axis and permitted static slide tilting torques:
depends on type, speed and loading; can be calculated with catalogue specifications
Materials Cylinder profile: Al anodized
End cover: Al painted
Seals, sealing band: NBR/PU
Guide band, reversal: POM
Guide rail: Al (slide guide), St (roller guide)
Driver: St, non−corroding (8/12), Al anodized (18...80)
Dirt wiper: NBR (8...18, 80), POM (25...63)
