7 Commissioning
Carry out a visual inspection before each start-up or re-start. Inspect the following before starting the
system:
• Electrical connections
• Correct seating, leak tightness and condition of piping and pipe connectors
• Correct seating and condition of compressed air connections if pneumatic valves are used
• Mechanical components for visible defects (cracks, loose connections etc.)
• Fill-level of tank B101, max. 3 litres of water in entire system
Eliminate any damage discovered during inspection before commissioning.
Supply the system with 24 V DC electrical voltage with a mains power supply unit.
8 Technical data
Technical data, system
Max. operating pressure in piping 50 kPa (0.5 bar)
Power supply for the station 24 V DC / 4.5 A (max. 100 W)
Profile plate 350 x 200 mm
Station height: with one tank
with two tanks
670 mm
1090 mm
EduKit Basic in cardboard box
outside dimensions
weight
560 x 393 x 280 mm (H x W x D)
9,25 kg
EduKit Advanced components in Systainer V
outside dimensions
weight
420 x 396 x 296 mm (H x W x D)
6,75 kg
Volumetric flow of the pump 0 to 10 l/min.
Tank for clean water Max. 3 litres
Flexible piping system DN15 (15 mm dia.)
Optional –
if 2-way ball valve is used:
Compressed air supply
operating pressure
600 kPa (6 bar)
