9 Scope of delivery
EduKit PA Basic
The following components are included in the scope of delivery. The data sheets are arranged in numeric
order.
Data sheets Designation Order no. Quantity
162844 Pressure gauge 162844 1
17070x Pipe, 4 Pcs. length 500 mm 304518 2 m
17070x Push-in L-connector 170701 2
17070x Push-in T-connector 170702 4
17070x Manual valve 170703 4
17070x Plug 170705 1
17070x 90° push-in bracket 690590 4
170712 Pump 170712 1
– Switching relay – 1
689200 Tank, round 689200 2
691225 Flow sensor, variable area principle (rotameter) 691225 1
— Rubber buffers 389603 4
— Electrical actuation components BG.EL.0190 1
— Type 5 slot nuts, M4, with stud BE.ME.0582 4
— Connecting plate BG.ME.0179 2
— Profile (20 x 40 x 180 mm) 660579 1
— Profile plate (20 x 200 x 350 mm) 532379 1
— Brief description 746310 1
Small parts included with EduKit PA Basic
Designation Quantity
Tubing D: MPS-PA-B-SCHL.15/1100 1
Length of pipe: MP-VT-P-15MM X 450 mm 4
Pipe clamps for PCS system: type 5 profile 2
Cable socket with socket head screw M 5x8 and type 5 slot nut 10
Socket head screw with internal hex: DIN 912 M 5x10 8.8, galvanised with washer and type 5 slot nut 2
Socket head screw with internal hex: DIN 912 M 5x16 8.8, galvanised with washer and type 5 slot nut 2
