5. Commissioning
5−11
Festo P.BE−MTR−DCI−IO−EN en 0606b
Current limiting
The motor current can be specified with 1 to 200 % of the
rated motor current depending on the specific application
(see FCT/PlugIn help MTR−DCI).
Positioning axis type DMES−... can carry out reference travel
with the factory−set current limitation (150 % of the rated
motor current). The current limitation need not be modified.
Current
limitation
1)
32 42 52 62
100 % Z
1 x rated motor current
motor current
motor torque
A
mNm
0.73
30
2.0
110
5.0
300
6.19
700
150 % (default) Z
1.5 x rated motor current
motor current
motor torque
A
mNm
1.1
46
3.0
171
7.5
460
9.29
1076
200 % Z
2 x rated motor current
motor current
motor torque
A
mNm
1.46
62
3.8
2)
220
7.7
2)
470
12.38
1450
1)
Parameter specification in FCT: relative motor current in % of rated current, setting range 1...200.
2)
Due to maximum current limitation the value does not rise further.
Tab.5/3: Current limitation
Please note
Please note the following when adapting the current
limitation:
By means of a current limitation, the maximum possible
speed of reference travel will also be reduced. The set
rated speed will therefore, in some cases, no longer be
achieved.
If the drive is arranged vertically, an increase in the
motor current may be
necessary. If the motor current is
too low, reference travel cannot be carried out.
