4. Control panel (MTR−DCI−...−H2IO)
4−6
Festo P.BE−MTR−DCI−IO−EN en 0606b
4.2 The menu system
4.2.1 Accessing the main menu
When the power supply is switched on, the MTR−DCI auto
matically carries out an internal check. At first the display
briefly shows the Festo Logo then changes to the status
display. The status display shows the following information:
 the type designation of your MTR−DCI
 the current position of the drive x
a
= ...
 the current setting of the device control
(HMI = Human Machine Interface)
The main menu is accessed from the status display with the
button <Menu>. The current button function will be displayed
in the lower lines of the LCD display.
Function
Button
<− −> With the arrow buttons on the control panel you
can select a menu item from the list. The current
selection is marked with an arrow (} Diagno
stic). Select the menu item S in order to display
further menu items (HMI control...).
v
V
ESC With <Menu> you can interrupt the current entry
and return in stages to the higher−order menu
level or status display.
Menu
OK With <Enter> you can confirm the current
selection or entry.
Enter
Tab.4/2: Button function (menu selection)
