Festo SPAE - LED and Display Meanings

6
Festo — SPAE — 2022-12c
Product overview
LED Display Meaning
One LED flashes Continuously on RUN mode: IO-Link communication active
Both LEDs off Function and Value flash
alternately
SHOW mode
Both LEDs flash alter-
nately
Continuously on or
flashing
EDIT mode: first menu option
Both LEDs flash simulta-
neously
Continuously on or
flashing
EDIT mode: second menu option or TEACH mode
Tab. 2: LEDs
Display Meaning
<Value> In RUN mode: current measured value in % FS
Single-digit pressure display values are displayed with a preceding under-
score,e.g._1
‘F0’ Switching function F0
è
4.2.2 Switching functions
‘F1’ Switching function F1
è
4.2.2 Switching functions
‘F2’ Switching function F2
è
4.2.2 Switching functions
‘F3’ Switching function F3
è
4.2.2 Switching functions
Threshold value comparator
Window comparator
‘P1’ Switching point P1 in % FS
‘P2’ Switching point P2 in % FS; not with switching function F0 and F1
‘HY’ Hysteresis in % FS:
Adjustable from 0…99, corresponds to 0 to 9.9% FS; not with switching function F2
‘Lo’ Minimum measured value in % FS
‘Hi’ Maximum measured value in % FS
‘Pn’ PNP switching output
‘nP’ NPN switching output
‘nc’ Switching logic normally closed contact
‘no’ Switching logic normally open contact
‘di’ Switch display on and off:
‘On’ = always on; ‘1’…‘20’ = switch off after 1…20 minutes
‘do’ Aligning the numeric indicator on the display:
‘do’ = default alignment; ‘op’ = rotated 180°
‘op’
