28
V&Hz Within Limits – The normal operating range is dened as being neither above the high warning or shutdown thresholds,
nor below the low warning or shutdown thresholds. Activated when measured generator voltage and frequency (that is
calculated as a percentage of rated voltage and frequency) are both within the normal operating range. This deactivates when
either the measured generator voltage or the frequency are outside the normal operating range.
2. SYSTEM EVENT
EVENT PARAMETER and EVENT TRIGGER condition need to be selected for SYSTEM EVENT. Table 6 is a list of available system
events.
SYSTEM EVENT
Pressure Gen Frequency
Engine Oil Pressure Gen Real Power
Gas Pressure Gen Voltage
Temperature Primary Data Link
Engine Coolant Temperature SCADA Data Link (PW2.1 Only)
Engine Oil Temperature Service Interval Expired
Exhaust Temperature Unexpected Eng S/D
Gen Rear Bearing Temp Earth Fault
Gen Winding #1 Temp Earth Leakage
Levels Engine Controller
Engine Coolant Level Fuel Leak
Engine Oil Level Air Damper Closed
Fuel Level Battery Charger Fail
External Tank Fuel Level Gen Breaker Open
Others Gen Breaker Closed
Any SPN
Custom Events
Accessory Data Link (PW2.1 Only) Digital Input #1 Custom Event
Battery Charging Sys Volt Digital Input #2 Custom Event
Battery Voltage Digital Input #3 Custom Event
Emergency Stop Switch Digital Input #4 Custom Event
Engine in Cooldown Digital Input #5 Custom Event
Engine Fail to Start Digital Input #6 Custom Event
Engine Speed Analog Input #1 Custom Event
Control Not in Auto Analog Input #2 Custom Event
Gen Current (Amp) Analog Input #3 Custom Event
Generator Circuit Breaker Closed Digital Input #5 Custom Event
Generator Circuit Breaker Locked Out Digital Input #6 Custom Event
Generator Circuit Breaker Failure to Open AnalogueInput #1 Custom Event
Generator Circuit Breaker Failure to Close AnalogueInput #2 Custom Event
Utility to Generator Transfer Failure AnalogueInput #3 Custom Event
Table 6
EVENT TRIGGER is used to select the desired condition in order to trigger the event. Table 7 is a list of the available trigger
conditions.
Any Warning FMI 02 Data Erratic: Intermittent or Incorrect
Any Shutdown FMI 03 Voltage Above Normal or Shorted to High Source
Any Warning or Shutdown
Low Warning FMI 04 Voltage Below Normal or Shorted to Low Source
High Warning FMI 05 Current Below Normal or Open Circuit
High / Low Warning FMI 06 Current Above Normal or Grounded Circuit
Low Shutdown FMI 07 Mechanical System Not Responding or Out of
Adjustment
High Shutdown FMI 08 Abnormal Frequency: Pulse Width or Period
High / Low Shutdown FMI 09 Abnormal Update Rate
Low Warning or Shutdown FMI 10 Abnormal Rate of Change
High Warning or Shutdown FMI 11 Root Cause Not Known
High / Low Warning or High / Low Shutdown FMI 12 Bad Intelligent Device or Component
High / Low Warning or High / Low Shutdown or Diagnostic FMI 13 Out of Calibration
Any Diagnostic
Condition Exists FMI 14 Special Instruction
Table 7
