1.8 Inputs & Outputs
1.8.1 Digital Inputs
Refer to the Digital Inputs section.
1.8.2 Digital Outputs
Refer to the Relay and Digital Outputs section.
1.8.3 Relay Outputs
Refer to the Relay and Digital Outputs section.
1.8.4 Analogue Inputs
The Analogue input coverts a resistive or Analogue voltage sender value to units and detects a high or low condition on the
sender input. An input can be selected for temperature, pressure and levels. Only the options associated with the selection will
appear on the menu. For example, if temperature is selected, some options related to pressure or level may not appear in the
menu.
Setpoints > Inputs & Outputs > Analogue Input (#1 to #3)
Setpoint Name
Min
Value
Max
Value
Resolution Units Factory
Default
Analogue Input Type Value list 0
Analogue Input Range Value list 0
Analogue Input Data Identication Value list 0
Analogue Input Conguration Code 1 25 1 N/A 1
Analogue Input Data Range Min -1 50000 0.01 N/A 0
Analogue Input Data Range Max -1 50000 0.01 N/A 100
Analogue Input High Warning Event Threshold 0 50000 1 N/A 100
Analogue Input High Warning Event Delay 0 240 0.10 sec 0
Analogue Input Low Warning Event Threshold 0 50000 1 N/A 0
Analogue Input Low Warning Event Delay 0 240 0.10 sec 0
Analogue Input High Shutdown Event Threshold 0 50000 1 N/A 100
Analogue Input High Shutdown Event Delay 0 240 0.10 sec 0
Analogue Input Low Shutdown Event Threshold 0 50000 1 N/A 0
Analogue Input Low Shutdown Event Delay 0 240 0.10 sec 0
Analogue Input Isolated Supply Voltage Value list 0
Analogue Input Common Supply Voltage Value list 0
