1.5 Generator Monitor / Protect
1.5.1 Enhanced generator monitor
Setpoints > Generator Monitor / Protect > Enhanced Generator Monitor
Setpoint Name
Min
Value
Max
Value
Units
Factory
Default
Description
Generator Winding Temperature Sensor
Installation Status
Value List
Set to “Installed” when a
temperature module is installed
on the accessory data link
Number of Generator Bearing Temperature
Sensors
Value List
1.5.2 Generator AC monitor
Setpoints > Generator Monitor/Protect > Generator AC Monitor
Setpoint Name
Min
Value
Max
Value
Units Description
Generator Connection Conguration Value List
Congurations can be: “Star/Wye”
“Delta/3 Wire”
“Delta/4 Wire”
“Single Phase 2 Wire” “Single Phase 3 Wire”
Generator Potential Transformer Primary
Winding Rating
1 50000 V
For direct sensing leave at default value.
For an application requiring a potential
transformer set to transformer primary
winding value.
Generator Potential Transformer Secondary
Winding Rating
1 240 V
For direct sensing leave at default value.
For an application requiring a potential
transformer set to transformer secondary
winding value
Generator Current Transformer Primary Winding
Rating
1 7000 A
Set to current transformer primary winding
value
Generator Current Transformer Secondary
Winding Rating
1 5 A Can only be set to 1 or 5
Number of Generator Poles 0 200 N/A
Generator Rated Frequency Value List
Generator Rated Voltage 100 50000 V
Generator Rated Power 1 50000 kW
Generator Rated Apparent Power 1 50000 kVA
1.5.3 Generator AC power monitor
The generator AC power monitor measures all generator power quantities, such as kW, kWh, kVAr, kVArh, kVA etc.
Setpoints > Gen Monitor/Protect > Gen AC Power Mon
Setpoint Name Min Value Max Value Units Factory Default
Customer Password Security Level to Reset
Generator Energy Meters
0 3 N/A 3
