FG Wilson PowerWizard 1.1+ - Generator over Current; Generator over; under Frequency; Generator over; under Voltage; Generator Reverse Power

47
1.5.4 Generator over current
Setpoints > Generator Monitor/Protect > Generator Over Current
Setpoint Name Min
Value
Max
Value
Units Factory
Default
Description
Generator Denite Time Over Current
(Amp) Warning Event Percentage
Threshold
80 130 % 100 Threshold for the Over Current Warning
Generator Inverse Time Over Current
(Amp) Shutdown Event Time Multiplier
0.05 10.00 N/A 0.27
Time multiplier setpoint (TM) used in
equation:
t = (TMx0.14)/[(I/Is)0.02-1]
Generator Denite Time Over Current
(Amp) Shutdown Event Percentage
Threshold
100 300 % 125
If current is above this setpoint value for
the specied time (setpoint #4) there
will be an overcurrent shutdown.
Generator Denite Time Over Current
(Amp) Shutdown Event Notication Delay
Time
0.1 20.0 sec. 10 Time delay for setpoint #3
1.5.5 Generator Over / Under Frequency
Setpoints > Generator Monitor/Protect > Generator Over/Under Freq
Setpoint Name Min Value
Max
Value
Units
Factory
Default
Generator Over Frequency Warning Event Percentage Threshold 80 120 % 105
Generator Over Frequency Warning Event Notication Delay Time 0.0 120 sec. 10
Generator Over Frequency Shutdown Event Percentage Threshold 80.0 120 % 110
Generator Over Frequency Shutdown Event Notication Delay Time 0.0 120 sec. 2
Generator Under Frequency Warning Event Percentage Threshold 80.0 120.0 % 95.0
Generator Under Frequency Warning Event Notication Delay Time 0.0 120 sec. 10
Generator Under Frequency Shutdown Event Percentage Threshold 80.0 120.0 % 90.0
Generator Under Frequency Shutdown Event Notication Delay Time 0.0 120 sec. 4
1.5.6 Generator Over / Under Voltage
Setpoints > Generator Monitor / Protect > Generator Over / Under Volt
Setpoint Name Min Value
Max
Value
Units
Factory
Default
Generator Over Voltage Warning Event Percentage Threshold 100 125 % 105
Generator Over Voltage Warning Event Notication Delay Time 0.0 120 sec. 10
Generator Over Voltage Shutdown Event Percentage Threshold 100 125 % 110
Generator Over Voltage Shutdown Event Notication Delay Time 0.0 120 sec. 2
Generator Under Voltage Warning Event Percentage Threshold 60 100 % 95
Generator Under Voltage Warning Event Notication Delay Time 0.0 120 sec. 10
Generator Under Voltage Shutdown Event Threshold 60 100 % 90
Generator Under Voltage Shutdown Event Notication Delay Time 0.0 120 sec. 4
1.5.7 Generator Reverse Power
Setpoints > Generator Monitor/Protect > Generator Reverse Power
Setpoint Name
Min
Value
Max Value Units
Generator Reverse Power Warning Event Percentage Threshold 1 20 %
Generator Reverse Power Warning Event Notication Delay Time 0 30 sec.
Generator Reverse Power Shutdown Event Percentage Threshold 1 20 %
Generator Reverse Power Shutdown Event Notication Delay Time 0 30 sec.
