FG Wilson PowerWizard 1.1+ - AVR Desired Voltage; Governor Desired Engine Speed; Engine Monitor; Protect; Battery Voltage Monitor

44
1.2.2 AVR Desired Voltage
Setpoints > Control > AVR Desired Voltage
Setpoint Name Min
Value
Max
Value
Units Description
Maximum Generator Voltage
Output Bias Percentage
0 100 %
The Maximum Generator Output voltage Bias Percent is the
maximum value above and below the Nominal Voltage that the
control will send a request for when adjusting the voltage from
the control screen
Generator Nominal Output
Voltage
100 50000 V
The Generator Nominal Output Voltage is the desired output
voltage of the generating set. This value is set to match the
generator rated voltage.
1.2.3 Governor Desired Engine Speed
Setpoints > Control > Governor Desired Engine Speed
Setpoint Name Min
Value
Max
Value
Units Description
Maximum Engine Speed Range 0 2000 rpm
The Maximum Engine Speed Range is the maximum value
above and below the Nominal Engine Speed that PowerWizard
will send a request for when adjusting the speed from the
control screen
Generator Nominal Output
Frequency
40 500 Hz This value is set to match the generator rated frequency
1.3 Engine Monitor / Protect
1.3.1 Battery Voltage Monitor
Setpoints > Engine Monitor / Protect > Battery Voltage Monitor
Setpoint Name Min
Value
Max Value Units
High Battery Voltage Warning Event Threshold 12 50 VDC
High Battery Voltage Warning Event Notication Delay Time 0.0 240 sec
High Battery Voltage Shutdown Event Threshold 12 50 VDC
High Battery Voltage Shutdown Event Notication Delay Time 0.0 240 sec
Low Battery Voltage Warning Event Threshold 0.0 25.0 VDC
Low Battery Voltage Warning Event Notication Delay Time 0.0 240 sec
Low Battery Charging System Voltage Warning Event Threshold 0.0 30 VDC
Low Battery Charging System Voltage Warning Event Notication Delay Time 0.0 240 sec
Low Cranking Voltage Warning Event Threshold 0.0 30.0 VDC
Low Cranking Voltage Warning Event Notication Delay Time 0.0 240 sec
1.3.2 Crank / Start Counter
Setpoints > Engine Monitor / Protect > Crank / Start Counter
Setpoint Name
Min
Value
Max
Value
Units
Factory
Default
Description
Customer Security Password Level to
Reset Crank / Start Counters
0 4 n/a 3 Password level required in order to reset the
Crank / Start Counters
