FG Wilson PowerWizard 1.1+ - Engine Speed Monitor; Enhanced Engine Monitor; Service Maintenance Interval; Events

45
1.3.3 Engine Speed Monitor
Setpoints > Engine Monitor / Protect > Engine Speed Monitor
Setpoint Name
Min
Value
Max
Value
Units Description
Flywheel Teeth 95 350 N/A
Engine Over Speed Shutdown Threshold 400 4330 rpm Set to 118% of rated speed
Engine Under Speed Warning Event Threshold 400 4330 rpm Set to 86% of rated speed
Engine Under Speed Warning Event Notication Delay
Time
0.0 20.0 sec.
Engine Under Speed Shutdown Event Threshold 400 4330 rpm Set to 82% of rated speed
Engine Under Speed Shutdown Event Notication
Delay Time
0.0 20.0 sec.
Engine Speed Sensor Conguration Value List
1.3.4 Enhanced Engine Monitor
Setpoints > Engine Monitor/Protect > Enhanced Engine Monitor
Setpoint Name
Min
Value
Max
Value
Units Description
Engine Cylinder Temperature Sensor Installation
Status
Value List Select “Installed” or “Not installed”
Number of Engine Cylinders 1 20 n/a
1.3.5 Service Maintenance Interval
Setpoints > Eng Monitor/Protect > Service Maintenance Interval
Setpoint Name Min
Value
Max
Value
Units Factory Default
Service Maintenance Interval Hours 0.0 2000 hours 500
Service Maintenance Interval Days 0.0 365 days 180
Customer Password Security Level to Reset Service
Maintenance Interval
0.0 4 N/A 3
1.4 Events
Description of Event Response Selection
Active Only Only displays event in the event log (no history on the event)
Warning Event logged, amber warning status LED
Audible Alert Activates relay output congured as “horn control”
Soft Shutdown Shutdown event allows cooldown cycle
Hard Shutdown Shutdown event skips cooldown cycle for fast engine shutdown
Breaker 1 Trip Activates relay output congured as “breaker 1 trip”
Breaker 2 Trip Activates relay output congured as “breaker 2 trip”
FTP Suppress the event until the engine is running and the fault protection timer has expired
