28
6.5 Heat Mode Parameters
parameter description
Template
Set sleeve type. List of all heat modes are displayed. Selected
mode will be copied to a user-programmable area.
Name Title for a heat mode.
Note
Title of the heat mode displayed in the bottom right corner of
the monitor during splicing or heating process. Max number of
characters used is 15.
Heater
control
Set the length of heat-shrink sleeve.
Long: protection sleeves over 30mm.
Short: 30mm protection sleeves or below.
Heater
temperature
Sets heating temperature.
Heater time Sets heating time from the beginning to the heating completed.
Cooling time Cooling fan operating Time
