FIBER FOX Mini 6S+ - Power Supply; Size and Weight; Environmental Conditions; Others

06
1.6 Size and Weight
Size：Length×width×height= 124mm×123.2mm×138mm
weight：1.52kg (without battery)
1.7 Environmental Conditions
Operating conditions: altitude: 0 to 5000m, relative humidity: 0 to 95%,
temperature: -10 to 50 ℃ , the maximum wind velocity: 15m / s;
Storage conditions: relative humidity: 0 to 95%, temperature: -20 to 60 ℃ ,
battery: -20 to 40 ℃ for long-term storage
1.8 Others
Observation and display: Two cameras (orthogonally view), 4.3-inch color LCD
touch screen
320x magnication for single X or Y view, or 160x magnication for both X and Y
view.
Tension test：1.96 to 2.25N.
Terminals:
Port Descriptions
SD card Inside the inner device, SD card drive, program for storage
USB External outside the device, data encryption function and image
save
1.5 Power Supply
AC 100-240V input or DC 9-14V
Lithium battery: 11.1V, 5.3Ah
Typical 220 cycles(Splice&Heat) / Single battery < 2 Batteries Standard >
