FiberHome AN5506-04-FS User Manual

3
Product Overview
T
able 3.1 Technical Parameters of the AN5506-04-A (Continued)
Type
Item
Description
Supports obtaining user IP address in DHCP mode;
supports reporting physical location of the Ethernet
interface using DHCP Option82.
Supports obtaining user IP address in the PPPoE
mode; supports the PPPoE+ function, used to
identify users accurately.
Supports encryption of downlink data using the
AES-128 algorithm.
QoS
Supports the ACL function to match traffic based on
the ACL rules.
Supports global configuration of queue priority and
flexible mapping of 802.1p values in packets.
Supports three queue scheduling modes (PQ, WRR
and PQ+WRR); supports configuring the weight of
the scheduled queue, so as to guarantee the service
quality of high-QoS services such as video in the
multi-service environment.
Network
side
interface
GPON
interface
Provides one GPON interface (SC/UPC or SC/APC
interface), supporting transmission distance up to
20km and complying with the ITU-T G.984 standard.
Supports Class B+, with receiving sensitivity less
than -29 dBm.
User side
interface
LAN
interface
Provides four LAN interfaces (RJ-45 interfaces),
supporting full-duplex or half-duplex and
10/100/1000M auto negotiation. The maximum
transmission distance is 100m.
MAC address capacity: 1K
6

FiberHome AN5506-04-FS Specifications

General

Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Wi-Fi	2.4 GHz
PON Interface	GPON
Ports	4 x 10/100/1000 Mbps Ethernet, 2 x POTS
