FiberHome AN5506-04-FS User Manual

4
Web Configuration Guide
T
able 4.24 Parameters for Configuration Backup
Item Description
Username The FTP username.
Password
The FTP password.
Localhost IP Local IP address.
File Name
The existing file name in the ONU.
4.6.2.4 FTP Client End
The
ONU serves as the FTP client end. Users can upload files to the
FTP server or download files from the FTP server.
1. Select Management in the navigation bar. Select Device
Management→Config Backup from the left link bar to open
the FTP client end tab, as shown in Figure 4.49.
Figure
4.49 FTP Client End
2
. Configure parameters relevant to the FTP client end. Table 4.25
describes the parameters.
3. Click Apply to save and apply the configuration.
124

FiberHome AN5506-04-FS Specifications

General

Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Wi-Fi	2.4 GHz
PON Interface	GPON
Ports	4 x 10/100/1000 Mbps Ethernet, 2 x POTS
