FiberHome AN5506-04-FS User Manual

4
Web Configuration Guide
T
able 4.6 Parameters for Broadband Settings (Continued)
Item
Description
IPv6
Addres-
s/Prefix
Select the IPv6 address obtaining mode /
prefix obtaining mode.
This item should be
set when IPv6 is
enabled and the
WAN IP Mode is set
to DHCP or PPPoE.
4.3.4
DHCP Server
Using
the DHCP function, the ONU can distribute the network
parameters (such as IP address, gateway and DNS server IP address)
to the devices (such as computer) within the LAN. Users can
manage the IP addresses collectively using the function.
1. Select Network in the navigation bar. Select DHCP Server
from the left link bar to open the DHCP server configuration tab,
as shown in Figure 4.16.
Figure
4.16 DHCP Server
84

FiberHome AN5506-04-FS Specifications

General

Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Wi-Fi	2.4 GHz
PON Interface	GPON
Ports	4 x 10/100/1000 Mbps Ethernet, 2 x POTS
