FiberHome AN5506-04-FS User Manual

3
Product Overview
T
able 3.10 Technical Parameters of the AN5506-04-DG (Continued)
Type
Item
Description
Network
side
interface
GPON
interface
Provides one GPON interface (SC/UPC or SC/APC
interface), supporting transmission distance up to
20km and complying with the ITU-T G.984 standard.
Supports Class B+, with receiving sensitivity less
than -29 dBm.
User side
interface
LAN
interface
Provides four LAN interfaces (RJ-45 interfaces),
supporting full-duplex or half-duplex and
10/100/1000M auto negotiation. The maximum
transmission distance is 100m.
MAC address capacity: 1K
Wi-Fi
Interface
2.4GHz; supports the 802.11b/g/n mode.
Supports four SSIDs and thirteen working channels;
supports automatic rate adjustment and launched
power adjustment.
Supports the OPEN, SHARED, WPA-PSK, WPA2-
PSK and WPAPSKWPA2PSK authentication
modes. Supports the TKIP, AES and TKIPAES
encryption modes.
USB
interface
Provides one USB interface. Supports USB2.0 /
USB1.1.
Table 3.11 Specifications of the AN5506-04-DG
Type
Item
Description
Mechanical
parameters
Dimensions
36mm × 211mm × 154mm
(height x width x depth).
Wall mounting hole
distance
121mm
Weight About 383g (5dB antenna)
24

FiberHome AN5506-04-FS Specifications

General

Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Wi-Fi	2.4 GHz
PON Interface	GPON
Ports	4 x 10/100/1000 Mbps Ethernet, 2 x POTS
