FiberHome AN5506-04-FS User Manual

3
Product Overview
T
able 3.16 Technical Parameters of the AN5506-04-FG (Continued)
Type
Item
Description
Supports three queue scheduling modes
(PQ, WRR and PQ+WRR); supports
configuring the weight of the scheduled
queue, so as to guarantee the service
quality of high-QoS services such as
voice and video in the multi-service
environment.
Network side
interface
GPON
interface
Provides one GPON interface (SC/UPC
or SC/APC interface), supporting
transmission distance up to 20km and
complying with the ITU-T G.984 standard.
Supports Class B+, with receiving
sensitivity less than -29 dBm.
User side
interface
LAN interface
Provides four LAN interfaces (RJ-45
interfaces), supporting full-duplex or half-
duplex and 10/100/1000M auto
negotiation. The maximum transmission
distance is 100m.
MAC address capacity: 1K
Phone
interface
Provides two phone interfaces (RJ-11
interfaces).
Wi-Fi Interface
2.4GHz; supports the 802.11b/g/n mode.
Supports four SSIDs and thirteen working
channels; supports automatic rate
adjustment and launched power
adjustment.
39

FiberHome AN5506-04-FS Specifications

General

Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Wi-Fi	2.4 GHz
PON Interface	GPON
Ports	4 x 10/100/1000 Mbps Ethernet, 2 x POTS
