3 Web Configuration Guide
2. Configure the parameters relevant to filtering as required. For details of the
parameters, see Table 3-16.
3. Click Apply to save and apply the configuration.
Table 3-16 Parameters of IPv6 Filtering
Item
Description
Uplink
Select the uplink filtering mode.
u White List indicates that the data complying with
the rules in the filtering rule table will be allowed
to pass.
u Black List indicates that the data complying with
the rules in the filtering rule table will not be
allowed to pass.
Click the Apply
button below to
apply the settings.
Downlink
Select the downlink filtering mode.
u White List indicates that the data complying with
the rules in the filtering rule table will be allowed
to pass.
u Black List indicates that the data complying with
the rules in the filtering rule table will not be
allowed to pass.
Direction
Sets the direction of the filtering rule.
u LAN->WAN: uplink direction.
u WAN->LAN: downlink direction.
Src IPv6
Enter the IPv6 address at the LAN side if the direction is set to LAN->WAN.
Enter the IPv6 address at the WAN side if the direction is set to WAN->LAN.
Src Port
The port range of the source IP address. This item is configurable when the
Protocol is set to TCP or UDP.
Dst IPv6
Enter the IPv6 address at the WAN side if the direction is set to LAN->WAN.
Enter the IPv6 address at the LAN side if the direction is set to WAN->LAN.
Dst Port
The port range of the destination IP address. This item is configurable when
the Protocol is set to TCP or UDP.
Protocol
The protocol type, including TCP, UDP, ICMP and ALL.
3.4.1.43.4.1.4 URL Filtering
By setting the URL filtering rules, users can forbid or allow all the data packets sent
to or received from a certain IP address. After the fire wall is enabled, the pre-set
URL filtering rule will take effect, and the domain names that meet the filtering
criteria will be filtered.
Version: A
55
