Fibocom FM101-GL User Manual

3 Application Interface
Copyright © Fibocom Wireless Inc. 16
Table 5. Pin Definition
Pin
Pin Name
I/O
Reset Value
Pin Description
Type
1
CONFIG_3
O
GND
GND, FM101 M.2 module is
configured as the WWAN – SSIC,
USB 3.0 interface type
-
2
+3.3V
PI
-
Power input
Power
Supply
3
GND
-
-
GND
Power
Supply
4
+3.3V
PI
-
Power input
Power
Supply
5
GND
-
-
GND
Power
Supply
6
FULL_CARD_
POWER_OFF#
I
PU
Power enable, module power on
input, internal pull up
3.3/1.8V
7
USB D+
I/O
-
USB data plus
0.3-3V
8
W_DISABLE1#
I
PD
WWAN disable, default high,
active low
3.3/1.8V
9
USB D-
I/O
-
USB data minus
0.3-3V
10
LED1#
OD
T
System status LED, output open
drain, CMOS 3.3V
3.3V
11
GND
-
-
GND
Power
Supply
12
Notch
Notch
13
Notch
Notch
