Fibocom FM101-GL User Manual

3 Application Interface
Copyright © Fibocom Wireless Inc. 17
Pin
Pin Name
I/O
Reset Value
Pin Description
Type
14
Notch
Notch
15
Notch
Notch
16
Notch
Notch
17
Notch
Notch
18
Notch
Notch
19
Notch
Notch
20
GPIO
I
PD
GPIO(I), default low, reserved
1.8V
21
CONFIG_0
-
NC
NC, FM101 M.2 module is
configured as the WWAN – SSIC,
USB 3.0 interface type
-
22
GPIO
I
PD
GPIO(I), default low, reserved
1.8V
23
WOWWAN#
O
PD
Wake up host, default low,
Reserved
1.8V
24
ANT_TUNER_1V
8
PO
PD
1.8V output for ANT Tuner,
reserved.
Power
Supply
/1.8V
25
DPR
I
PD
Dynamic power reduction detect,
default high, active low
3.3/1.8V
26
W_DISABLE2#
I
PD
GNSS disable, default high, active
low, reserved
3.3/1.8V
27
GND
-
-
GND
Power
Supply
28
GPIO
I
PD
GPIO(I), default low, reserved
1.8V
